| Feature | Description | Unit |
| Capacity | ||
| Swing over carriage | 670 | mm |
| Chuck dia. Max | 304 | mm |
| Max. Turning Diameter | 394 | mm |
| Max. Turning Length | 392 | mm |
| Main Spindle | ||
| Spindle nose | A2-8 | type |
| Hole through Spindle | 56 | mm |
| Maximum spindle.speed | 2500 | rpm |
| Spindle motor power (cont./15min) | 15 / 18.5 | Kw |
| Feed | ||
| Travel X - Axis | 275 | mm |
| Travel Z - Axis | 465 | mm |
| Rapid traverse (X/Z) - Axes | 20 / 20 | m/min |
| Turret | ||
| No. of Stations | 12 | nos. |
| Tool Shank Size | 25 x 25 | mm |
| Maximum Boring Bar Diameter | 40 | mm |
| Turret Indexing | Hydraulic | Type |
| Turret Indexing time | 1 to 1.5 | sec |
| CNC System | ||
| CNC System | Fanuc | Type |
| Machine Size | ||
| L x B x H | 1830 x 2870 x 2820 | mm |
| Weight | 6600 | kgs |
